- 7.3L (444) DI V8 TURBO-DIESEL ENGINE-inc: 130 amp alt, dual 78 amp/hr batteries, engine block heater, exhaust back pressure valve
Selected Equipment
- 4WD
- AM/FM Stereo
- Air Conditioning
- Dual Rear Wheels
- Power Steering
- Tilt Wheel
- XLT

Please Note: The included equipment is based on the dealership's bookout process and manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.

Safety
- Color-keyed safety belts w/front seat adjustable D-rings
- Dual-note horn
Exterior
- Chrome front bumper w/lower center trim
- Argent box-rail/tailgate moldings
- Argent grille w/chrome surround
- Aero halogen headlights
- Pickup box/cargo light
- Roof clearance lights
- Black manual fold-away mirrors
- Solar tinted glass
- Interval wipers
- Black door handles
- Removable locking tailgate w/black handle
Interior
- Forward-folding rear flight bench seat
- Color-keyed carpet full-floor covering
- Color-keyed scuff plates
- Black vinyl steering wheel
- Instrumentation-inc: tachometer, trip odometer, voltmeter, oil pressure/ coolant temp/fuel gauges, indicator lights
- Inside hood release
- (4) air registers w/positive shut-off
- Color-keyed instrument panel w/dual cupholders/glove box/ashtray/cigar lighter
- Auxiliary pwr point
- Color-keyed molded door trim panel-inc: soft armrest, grab handle,reflector, upper vinyl insert, carpeted map pocket
- 11.5" day/night mirror
- Color-keyed molded cloth headliner
- Front passenger assist handle
- Grab handles mounted over rear doors
- Color-keyed cloth sun visors-inc: LH strap, RH mirror
- Dual color-keyed coat hooks
- Dual dome lamps w/time delay off
- Dual map lights
- Underhood service light
- Gray fabric back panel cover
Mechanical
- 2-speed transfer case
- 3.73 axle ratio
- Four wheel drive
- Manual locking front hubs
- 72 amp/hr (650 CCA) maintenance-free battery
- 95 amp alternator
- 4-pin trailer tow wiring connector
- 172" WB
- 8' pickup box w/tie-down hooks & partitionable/stackable storage
- (2) front tow hooks
- 11,200# GVWR (4700 front/8250 rear), springs (4700 front/8250 rear), axles (4700 front/10,000 rear)
- Mono-beam front axle
- Front stabilizer bar
- HD gas shock absorbers
- Pwr steering
- 38 gallon fuel tank

Please Note: These features are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.

Chassis
- Frame
  - Frame Type: Ladder-Type
- Tires
  - Front Tire Size: LT235/85R16E
  - Rear Tire Size: LT235/85R16E
  - Front Tire Capacity: 2778 lbs
  - Rear Tire Capacity: 2778 lbs
- Brakes
  - Brake Type: Power
  - Brake ABS System: 4-Wheel
  - Disc - Front (Yes or ): Yes
  - Disc - Rear (Yes or ): Yes
  - Front Brake Rotor Diam x Thickness: 13.03 x - TBD - in
  - Rear Brake Rotor Diam x Thickness: 12.83 x - TBD - in
- Wheels
  - Front Wheel Size: 16 x 6.0 in
  - Rear Wheel Size: 16 x 6.0 in
- Steering
  - Steering Type: Power
  - Steering Ratio (:1), On Center: 17.1
  - Steering Ratio (:1), At Lock: - TBD -
  - Turning Diameter - Curb to Curb: 61.7 ft
  - Turning Diameter - Wall to Wall: 64.3 ft
- Fuel Tank
  - Fuel Tank Capacity, Approx: 38 gal
  - Fuel Tank Location: Midship
- Suspension
  - Suspension Type - Front: Single-Stage Leaf
  - Suspension Type - Rear: Multi-Leaf
  - Axle Type - Front: Dana Monobeam
  - Axle Type - Rear: Ford Full-Floating
  - Axle Capacity - Front: 5200 lbs
  - Axle Capacity - Rear: 9750 lbs
  - Shock Absorber Diameter - Front: 35 mm
  - Shock Absorber Diameter - Rear: 35 mm
  - Stabilizer Bar Diameter - Front: - TBD - in
- Trailering
  - Dead Weight Hitch - Max Trailer Wt.: 5000 lbs
  - Dead Weight Hitch - Max Tongue Wt.: 500 lbs
  - Wt Distributing Hitch - Max Trailer Wt.: 10000 lbs
  - Wt Distributing Hitch - Max Tongue Wt.: 1000 lbs
  - Fifth Wheel Hitch - Max Trailer Wt.: 14300 lbs
  - Fifth Wheel Hitch - Max Tongue Wt.: 3575 lbs
- Weight Information
  - Gross Axle Wt Rating - Rear: 8250 lbs
  - Gross Combined Wt Rating: 20,000 lbs
Vehicle
- Vehicle
  - Country of Origin: United States Ford Truck
Dimensions
- Exterior Dimensions
  - Wheelbase: 172.4 in
  - Length, Overall w/o rear bumper: 257.6 in
  - Width, Max w/o mirrors: 95.5 in
  - Height, Overall: 80.6 in
  - Overhang, Front: 37.4 in
  - Overhang, Rear w/o bumper: 47.8 in
  - Front Bumper to Back of Cab: 153.6 in
  - Cab to Axle: 56.2 in
  - Cab to End of Frame: - TBD - in
  - Ground to Top of Load Floor: 37.3 in
  - Ground to Top of Frame: - TBD - in
  - Frame Width, Rear: - TBD - in
  - Ground Clearance, Front: - TBD - in
  - Ground Clearance, Rear: - TBD - in
- Interior Dimensions
  - Front Head Room: 41.4 in
  - Front Leg Room: 40.7 in
  - Front Shoulder Room: 68.0 in
  - Front Hip Room: 67.4 in
  - Second Head Room: 41.0 in
  - Second Leg Room: 42.5 in
  - Second Shoulder Room: 68.0 in
  - Second Hip Room: 67.3 in
- Cargo Area Dimensions
  - Cargo Box Length @ Floor: 98.6 in
  - Cargo Box Width @ Top, Rear: 64.6 in
  - Cargo Box Width @ Floor: - TBD - in
  - Cargo Box Width @ Wheelhousings: 50.9 in
  - Cargo Box (Area) Height: 20.0 in
  - Tailgate Width: 65.0 in
  - Cargo Volume: 77.7 ft³
Powertrain
- Engine
  - Engine Order Code: 99F
  - Engine Type: Diesel V8
  - Displacement: 7.3L/444
  - Fuel System: Turbo-Charged DI
  - SAE Net Horsepower @ RPM: 235 @ 2700
  - SAE Net Torque @ RPM: 500 @ 1600
  - Engine Oil Cooler: - TBD -
- Electrical
  - Cold Cranking Amps @ 0° F (2nd): 750
- Transmission
  - Drivetrain: 4-Wheel Drive
  - Transfer Case Gear Ratio (:1), High: 1.00
  - Transfer Case Gear Ratio (:1), Low: 2.72

Please Note: These technical specifications are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.

Safety
- Safety features
  - Tow Hooks
- Air bag - frontal
  - Driver Air Bag
Chassis
- Brakes
  - ABS
  - 4-Wheel Disc Brakes
- Steering
  - Power Steering
Seating
- Seats
  - Rear Bench Seat
Powertrain
- Fuel
  - Diesel Fuel
- Engine
  - 8 Cylinder Engine
  - Turbocharged
- Drivetrain
  - Four Wheel Drive
  - Dual Rear Wheels
Accessories
- Audio
  - AM/FM Stereo
  - Cassette
- Convenience
  - Intermittent Wipers
  - Power Outlet
  - Front Reading Lamps

Please Note: These options are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.

Factory Warranty
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 2
- Drivetrain Miles/km: 24,000
- Corrosion Years: 5
- Corrosion Miles/km: Unlimited
- Roadside Assistance Years: 3
- Roadside Assistance Miles/km: 36,000

Please Note: This information is based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
